Automatic Double Side Sealer & Shrink Wrapping Machine


Longer and wider products such as door, window, cloth roll, pallet, wooden board, etc.

Sealing type 380V/50-60Hz/3phase
Sealing height ≤200 mm
Sealing width≤350 mm
Product sizewidth+height≤400mm
Product lengthinfinite
Packing capacity depends on product length
Film typecenter-folded polyolefin (POF) film or polyethylene(PE)film
Max film size580mm(width) x 280mm(outer diameter)
Power consumption10.5kW
Tunnel oven sizedepends on product length
Tunnel conveyor speedvariable
Tunnel conveyor chains with rotating silicon coated rods
Working height 780-820 mm
Air pressure≤0.5MPa
Sealing system Special durable alloyed sealing knife with anti-stick Teflon coats
Operating panelSiemens colorful touch screen, PLC, Omron temperature controller
